11kw Silent Diesel Generator Set
11kw Silent Diesel Generator Set
- Kotengen
- China
- 20-25days
- 500set per month
Koten Power Air Cooled Diesel Generator Set
50Hz 11KW Rated Power , 60Hz 12KW Rated Power.
Main Features
Hydraulic-Magnetic circuit breaker
Low oil shut down protection system
Double mufflers for quiet operation ,low noise and low fuel consumption
Elegant outlook with arc-shaped design and compact structure
Economical and environment protection
Stronger power with bigger output torque and stable output frequency.
Stand configuration wheel kit and electric start
Smoothly running ,lower vibration
Convenience in operation and maintenance of housing design with top-flip cover.
High capacity fuel tank for long running.
<
| Model | KD12000SE/3 | KD13000SE/3 | |||
| Generator | Rated Frequency (Hz) | 50 | 60 | ||
| Rated Speed(rpm) | 3000 | 3600 | |||
| Rated Voltage (V) | 230 | 230/400 | 110/220 | 127/220 | |
| Rated output Power (kW) | 11 | 11 | 12 | 12 | |
| Max output Power (kW) | 12 | 12 | 13 | 13 | |
| Power factor | 1 | 0.8 | 1 | 0.8 | |
| Phase Number | Single | Three | Single | Three | |
| Excitation model | Brush self excited constant voltage (with AVR) | ||||
| Insulation class | F | ||||
| Pole number | 2 | ||||
| Engine | Engine Model | KD2V92 | |||
| Engine type | V2 Cylinder air cooled diesel | ||||
| Bore x Stroke (mm) | 92x75 | ||||
| Displacement (cc) | 996 | ||||
| Lubrication oil volume(L) | 1.7 | ||||
| Fuel type | 0#(Summer),-10#(Winter) Diesel Fuel | ||||
| Lubrication type | SAE10W30(CD grade above) | ||||
| Genset | Oil consumption (g/kw.h) | ≤250 | |||
| Tank capacity (L) | 15 | ||||
| Noise Dba (@7m) | 75-77 | ||||
| Net Weight(kgs) | 265 | ||||
| Dimension(LxWxH) mm | 1125*640*895 | ||||
| Qty for 20GP | 36 | ||||
| Qty for 40HQ | 96 | ||||
| Starting system | Electric Starter | ||||
