Kofo Series 32KW 40KVA Sound Proof Diesel Generator Set
  • Koten
  • Fujian China
  • 20-25days
  • 200pcs per month

Koten Ricardo Kofo Series Generator With Prime Power:
32kW/40kVA @50Hz 400V
40kW/50kVA @60Hz 220V

Koten Power Diesel Generator Set Powered By Ricardo Kofo Engine.

50Hz ,400V Three Phase Prime Power 32KW / 40KVA.

60Hz, 220V Three Phase Prime Power 40KW / 50KVA.

40kVA diesel generator

Koten Power Ricardo Kofo series generators which equiped with Kofo engine. Shandong Kofo Co., Ltd. is a collection of diesel engine research and development, manufacturing, sales as one of the specialized high-tech enterprises. The main products of the company are R, 100, Y80 and Steyr four series diesel engine, power range from 10Kw to 360Kw, the company has a technical team and management team with more than twenty years of experience in the production of diesel engine, adhere to the market oriented, customer demand as the focus. this brand engine are very popular in Southeast Asia, South American, Middle East and South Africa markets and so on.

Features & Benefits Of Yangdong Engine:

  • Easy service and maintance.

  • Adapt to harsh environment high altitude, extreme hot and cold environment and maintance.

  • Compact design

  • 50 degree ambient temperature approved.

  • Low operation cost.

Aplication:

Koten gensets had been widly applicated for hospital, factories, shopping mall, hotel, banks, telecommunictaion, residential, airport, stations, military ect.

1,Technical data.

Genset SpecificationGenset ModelKDR-40/SKDR-50/S
Frequency50Hz60Hz
Prime Power32kW40kVA40kW50kVA
Standby Power35kW44kVA44kW55kVA
Rated Voltage400/230V220/127V
Rated Current57.6A131A
Engine SpecificationEngine BrandRicardo Kofo
ModelN4100ZDS
AspirationTurbocharged
Fuel SystemDirect Inject
No.Cylinders4 in line
Displacement3.61 L
Bore * Stroke100*115mm
Compression Ratio19.0:1
Raated Speed1500rpm1800rpm
Rated Power (With Fan)42kW46kW
Governor TypeElectricalElectrical
Start Motor24V
Alternator SpecificationAlternator BrandKoten KA-184JKoten KA-224D
Phase3
Voltage400/230V220/127V
Wiring Type3 Phase 4Wire,Y Type
BearingSingle
Power Factor0.8
Frequency50Hz60Hz
Prime Power34kW40kW
Exciter TypeBrushless, Self-Excitation
Voltage Regulation± 1%
Protection GradeIP23
Isulation GradeH/H
Altitude1000m
Control ModuleStandardSmartGen
ModelHGM6120N
Protective Functions★Low Oil PressureImage
★High Water Temperature

32kw diesel generator set

★High/Low Voltage
★High Engine Temperature And Overspeed
★Emergency Stop
★Start Failure
★Automatic mains failure
OptionalDeepseaComAp

32kw sound proof diesel generator

40kVA diesel generator

2.Genset Configuration:

Standard:

  • Genset coupled with Ricardo Kofo engine with heavy-duty air filter, oil filter, fuel filter, fuel and water separator. Standard Koten brand brushless ac alternators. Alternator optional for Stamford, Leroy Somer, Marathon, Meccalte.

  • Large size radiator.

  • Heavy duty antivibration pad.

  • Heavy duty steel base frame with 8 hours continues working fuel tank.

  • The thickness of the canopy is 2mm at least with high quality paint materials and strict powder paint processing.

  • High quality door locks and hinges and 180° revolvable with disassemble door for easy maintenance.

  • large-scale impedance combined type muffler with high quality soundproof and insulation materials to ensure the low noise level for the generators.

  • High quality maintenance-free battery with connecting cables.

  • Standard mcb or mccb with brand Delixi. Optional for Chint,ABB ect.

  • Standard Smartgen HGM6120N control moduel with AMF function, Optional for Deepsea, ComAp, Datakom,Deif ect.

  • Genset standard with battery charger and ATS connection port.

  • Genset standard with 4 lift eyes, lift pockets on the base frame and lifting port on the top of the canopy which ensure the gensets can be transport easily.

Optional:

  • Water jacked heater.

  • Radiator water level sensor.

  • Oil heater.

  • Space heater.

  • ATS and synchronization panels.

  • Daliy fuel tank.

  • PMG for alternator.

32kw diesel generator set
